Invensys MF41-6343 Floating Valve Actuator, NSR, 24V, 300 lb-in
Actuator: (MF41-6343):
- Actuator Type: Electric
- Control Signal: Floating
- Loss of Power Type: Non-Spring Return
- Power Input Voltage: 22 to 30 VDC, 24 VAC/VDC
- Leads and Connections: 3 ft Plenum
- Torque: 300 in-lb
- Mechanical Movement: Rotary
- Protection Rating: NEMA 1, NEMA 4
- Product Line: Schneider Electric
- Product Range: SmartX Actuator
- Product Series: Mx4x-6xxx
- Actuator Use: Dampers, Globe Valves
Product Alert: Linkage required for Globe Valve Assembly use. NEMA 4 with customer supplied water tight conduit connectors.
Product Specifications
| Actuator Housing Material | Aluminum die cast |
| Actuator Type | Electric |
| Actuator Use | Dampers |
| Globe Valves | |
| Auxiliary Switch | No |
| By Schneider | Yes |
| California Residents |  WARNING:This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Conduit Connection | 1/2 in |
| Control Signal | Floating |
| Duty Cycle | 100% |
| Humidity | 5 to 95% non-condensing |
| Insulation Class | Class II |
| IP Protection Rating | IP10 |
| IP56 | |
| Lead Length | 3 ft |
| Leads and Connections | Plenum |
| Loss of Power Type | Non-Spring Return |
| Mechanical Movement | Rotary |
| Motor Type | AC Synchronous |
| NEMA Protection Rating | NEMA 1 |
| NEMA 4 | |
| Override | Automatic reset |
| Position Indicator | Pointer and scale |
| Power Consumption Holding VA | 4.10 VA |
| Power Consumption Holding VA DC | 3.00 VA |
| Power Consumption Running VA | 5.70 VA |
| Power Consumption Running VA DC | 4.10 VA |
| Power Consumption Running Watts | 3.90 W |
| Power Input Frequency | 50 Hz |
| 60 Hz | |
| Power Input Voltage | 22 to 30 VDC |
| 24 VAC | |
| 24 VDC | |
| Power Input Voltage AC Tolerance | Plus or minus 20% |
| Power Input Voltage DC Tolerance | Plus 25% or minus 8% |
| Product Range | SmartX Actuator |
| Product Series | Mx4x-6xxx |
| Rotation | 101 degrees |
| Rotation Tolerance | Plus or minus 1 degrees |
| Rotational Range Adjustment | 0 to 101 degrees |
| Temperature Ambient Operating Range | -31.6 to 60 C (-25 to 140 F) |
| Temperature Shipping and Storage Range | -40 to 71 C (-40 to 159.8 F) |
| Torque | 300.00 in-lb |
| 33.89 Nm |
Documents
| Selection guide | Spring-Return and Non-Spring Return Direct Coupled SmartX Actuators |
| Weight | 8 lbs |
|---|---|
| Dimensions | 2 × 2 × 2 in |
| Manufacturer |
